Cummins Onan Propane RV Generator, 2.5 kW

Call us for price, installation  and delivery affairs.

RV generator set Quiet Gasoline/PropaneTM Series RV QG 2800

• Model: EX 21
• Design: 4-cycle, single cylinder, OHC
• Displacement: 13.2 in3 (217 cm3)
• Compression ratio: 8.5:1
• Power: 7.0 bhp (max) at 3600 r/min
• Cooling: Pressurized air
• Cooling air volume: Includes engine cooling air volume
• 60 Hz: 300 ft3/m (8.5 m3/min) at 3600 r/min
• 50 Hz: 250 ft3/m (7.1 m3/min) at 3000 r/min
• Fuel system: (Gasoline) electric fuel pump, fuel lift 3 ft (914 mm); (LP) electric fuel solenoid; automatic choke Combustion air:
• 60 Hz: 12.5 ft3/m (0.35 m3/min) at 3600 r/min
• 50 Hz: 10.4 ft3/m (0.3 m3/min) at 3000 r/min
• Ignition system: Breakerless, electronic
• Starting system: Remote, 12 V, 3-wire negative ground; start-stop rocker switch on control; connector for remote start cable
• Lubrication: Splash lubrication
• Oil capacity: 0.6 qt (0.63 L)
• Cylinder crankcase: Alloy aluminum with iron cylinder liner cast into the bloc

2.5HGJBB-1121A

• Model: EX 21
• Design: 4-cycle, single cylinder, OHC
• Displacement: 13.2 in3 (217 cm3)
• Compression ratio: 8.5:1
• Power: 7.0 bhp (max) at 3600 r/min
• Cooling: Pressurized air
• Cooling air volume: Includes engine cooling air volume
• 60 Hz: 300 ft3/m (8.5 m3/min) at 3600 r/min
• 50 Hz: 250 ft3/m (7.1 m3/min) at 3000 r/min
• Fuel system: (Gasoline) electric fuel pump, fuel lift 3 ft (914 mm); (LP) electric fuel solenoid; automatic choke Combustion air:
• 60 Hz: 12.5 ft3/m (0.35 m3/min) at 3600 r/min
• 50 Hz: 10.4 ft3/m (0.3 m3/min) at 3000 r/min
• Ignition system: Breakerless, electronic
• Starting system: Remote, 12 V, 3-wire negative ground; start-stop rocker switch on control; connector for remote start cable
• Lubrication: Splash lubrication
• Oil capacity: 0.6 qt (0.63 L)
• Cylinder crankcase: Alloy aluminum with iron cylinder liner cast into the bloc

Standard features

• Cummins Onan sound-attenuating enclosure
• Focalized mounting system with vibration isolators
• Cross-flow cooling
• Sheet steel drip controlling base
• Enclosed muffler
• Integral USDA Forest Service approved spark arrestormuffler
• Adjustable mechanical governor
• Automatic choke
• Overhead cam
• Single-side service
• Low oil level shutdown
• Electric fuel pump (gasoline); electric solenoid (LP)
• Mounted control panel
• Sealed remote start connector
• Electric start
• Fused DC circuits to protect set wiring and remote control wiring
• Magnetic circuit breaker
• 50 in (1.3 m) generator set output leads
• Solid-state ignition
• Standard onboard diagnostic capability

3 year warranty, please refer to the manufacturer's manual
