Elios Arbora P4-C | Pole Mount System for 4 Solar Panels | Post Mounting System

The Elios Arbora P4-C Solar Panel Pole Mount System is a durable top-of-pole mounting solution designed to support four solar panels in a horizontal configuration. Engineered for residential, commercial, and off-grid solar installations, it provides a stable and reliable foundation while allowing the tilt angle to be adjusted for improved seasonal solar exposure and energy production.

Designed for installation on a reinforced concrete foundation with anchor bolts, the Arbora P4-C delivers excellent stability in demanding weather conditions. Depending on the solar panels used, the system supports approximately 1,300 to 1,800 watts of nominal solar capacity. When paired with bifacial solar panels, reflected sunlight can increase total system output to up to 3,000 watts under ideal conditions.

The kit includes the essential components required to assemble the pole mount system. The mounting post is manufactured from galvanized steel, while the upper racking is finished in black-painted galvanized steel. Minor paint imperfections or small chips may occur during shipping and do not affect the structural integrity or performance of the system.

Galvanized post included.
