Victron Energy MultiPlus 48/2000/25-50 120V VE.Bus | PMP482200100

The Victron Energy MultiPlus 48/2000/25-50 is a compact and reliable all-in-one inverter/charger that combines a 1600W pure sine wave inverter, 25A smart battery charger, and a 50A transfer switch. Ideal for off-grid, backup, and mobile applications, it ensures seamless power delivery from batteries, solar, or the grid.

With fast transfer time, remote monitoring, and the ability to connect in parallel or 3-phase configurations, the MultiPlus offers dependable performance and flexible energy management in one rugged unit.

Key Features:

• Reliable Power Output: Delivers 1600W continuous and 3500W surge power to support essential appliances and equipment.
• Smart Battery Charging: Adaptive 4-stage charging maximizes battery life with precise current control.
• Multiple Power Inputs: Supports grid, generator, and battery sources for continuous power availability.
• Fast Transfer Time: Switches to inverter power in under 20ms to protect sensitive electronics.
• Remote Monitoring: Integrates with VictronConnect app and VRM Portal for real-time tracking and remote management.
• Parallel & 3-Phase Ready: Supports up to 6 units in parallel or 3-phase for higher capacity and flexibility.
• Dual AC Outputs: Independent AC outputs for priority and non-priority loads during backup mode.
• Compact and Lightweight: Space-saving design with efficient cooling and rugged housing.
• VE.Bus Communication: Seamless system expansion and configuration via Victron GX devices.


Applications:

• Off-Grid | Backup Power Systems | Mobile/RV | Marine | Residential | Light Commercial

Certification:

• Safety: EN 60335-1 / EN 60335-2-29
• EMC: EN55014-1 / EN55014-2
• Grid Compliance: UL certified versions available upon request

Additional Information:

Inverter Continuous Power: 1600W at 25°C
Inverter Peak Power: 3500W
Battery Charger Output: 25A
AC Input Current: 50A Transfer Switch
Nominal Battery Voltage: 48V
Output Voltage: 120V AC
Communication Ports: VE.Bus, remote monitoring compatible
